• Feature

Unloading Tray to Auto Stacker type
( Lead frame + Paper )
- Auto System / Master Type Tool
- Adjustable Multi type rail
- Optional Vision for inspection
- Easy to handle / Increase the productivity to shorten the
  product cycle time
- Small space with high efficiency
- Easy to change and handle the Device
- Simple design / Comparative price with high quality

• Station Process

Reel Feeding loading - Vision inspection (Option) -
Piercing + Cutting - Tray to stacker( Lead Frame )

• Performance

- Air hydro cylinder press 2ton
- Servo motor feeding for Gripper
- Reel to Tray to Auto stacker ( Lead Frame )
- SPM: Max. 45 (High Productivity)
- Feeding Length : Max. 300mm
- Reel Width : Min. 40 ~ Max. 80mm
- L/Frame Thickness : T0.125mm ~ T0.3mm
- Omron PLC + Touch Screen

• Applicable Frame

Side View , Top View, Power, etc…
